TROUBLESHOOTING TIPS

SPECIFICATIONS

VWD2636

Output per hr: Hot 1.3 gal / 5.0 L

Cool 0.1 gal / 0.4 L

Internal Tank: Hot 0.16 gal / 0.6 L

Cool 0.2 gal / 0.8 L

Heating Temp (approx.): 194°F / 90°C

Cooling Temp (approx.): 50°F / 10°C

Power Consumption: Hot 1300 W

Cool 75 W

Problem Possible Cause Suggested Solution

Water dispenser is leaking Small pin hole or crack in the bottle, Conduct water bottle leak test outlined

(common with recycled water bottles). on page 4.

Drain cap and silicone seal are not secure. Ensure seal is secure in drain plug and

tighten drain cap.

Water was poured directly into bottle Drain by pressing dispenser buttons.

support collar and overflowed.

Water is not hot or All the water in the tank has been used. Replace with full bottle and wait 30

cold enough minutes for the water to heat or cool.

The unit is unplugged. Plug it into the outlet.

Insta-HOT was not activated. Activate Insta-HOT by pressing the button.

The circuit breaker in your home is Reset the breaker or replace the fuse.

tripped or the fuse has blown.

Cool water power switch is not Turn switch to the ON position.

turned on at back of unit.

Temperature limiter tripped. Set power switch to OFF position,

wait 5 minutes, then set power

switch to the ON position. Wait 30

minutes for the water to heat or cool.

Water dispenser is not Empty water bottle. Replace with full bottle.

dispensing water

Mineral deposits clogging tanks. See Cleaning the Reservoirs.

Possible air pocket. Push down on the dispenser buttons to

prime the unit.

Water dispenser is noisy Bottle making a gurgling noise as it This is normal.

fills the tank.

Water dispenser is uneven. Make sure the dispenser is on an even

surface that can support its full weight.

WARNING: The Water Dispenser

heats and dispenses water to

194˚ F / 90˚ C which can cause

severe burns or scalding.

DO NOT ALLOW CHILDREN TO USE

THE HOT WATER DISPENSING

BUTTON WITHOUT PROPER AND

DIRECT SUPERVISION.

Childproof

safety

switch
